Model
|
SY-LP01
|
SY-LP02
|
|
system structure
|
Embedded RTOS design, dual-core 32-bit DSP (Hi3518EV201), pure hard compression, watchdog
|
|
sensor
|
1 million 1/4" SC2145H CMOS sensor; color 0.1Lux@F1.2, black and white 0.01Lux@F1.2
|
2 million 1/3" SC2235P CMOS sensor; color 0.1Lux@F1.2, black and white 0.01Lux@F1.2
|
|
Video processing
|
H.264+/H.264 video encoding, support dual stream, AVI format; support code stream 0.1M~6Mpbs adjustable; support frame rate 1~30 frames/sec adjustable
|
|
Image output
|
Main stream: 1280*720@25fps; sub-stream:
|
ain stream: 1920*1080@25fps; sub-stream: 704*576@25fps
|
|
shutter
|
1/50 (1/60) seconds to 1/10000 seconds
|
|
Lens
|
M12 lens
|
|
Day and night conversion mode
|
IR-CUT infrared 6 light night vision
|
|
Noise reduction
|
Support 2D/3D noise reduction
|
|
Audio processing
|
G.711A codec standard, support two-way voice intercom function, support audio and video synchronization
|
|
Signal interface
|
1 photoresistor interface,1 IR-CUT drive interface, support photo resistance input signal and IR-CUT, infrared light linkage
|
|
PIR human body induction
|
PIR infrared human body sensor that supports passive infrared sensing
|
|
WIFI antenna interface
|
1 WIFI antenna interface,support for wireless network connection, one-button WPS function
|
|
Reset button interface
|
Support one-button reset
|
|
SD card slot
|
Supports up to 8-128GB (128G only supports low speed cards)
|
|
Battery specification
|
Standard 18650 lithium battery is available
|
|
reliability
|
Comprehensive lightning protection, in line with national international standards; 7*24 hours 65°C high temperature test is stable and reliable (including complete machine test)
|
|
Features
|
Support WEB configuration, OSD, motion detection; center reminder after motion detection alarm, screen pop-up linkage; support MJPEG capture; support client remote monitoring software, MYEYE platform and other system applications; provide complete SDK development kit
|
|
Power consumption
|
Standby mode: 450uA / working mode: 230mA
|
|
ONVIF
|
not support
|
|
Phone monitoring
|
Support mobile phone monitoring(iOS, Android)
|
|
power supply
|
Power supply (optional): 1, DC5V; 2, 1 * 18650 power supply (support charging)
|
|
other
|
Does not support any customization at this time
|
|
Product Size
|
42mm*42mm*125mm
|
|
Color box size
|
75mm*85mm*197mm
|
|
weight
|
Net weight: 100g Gross weight: 310g (Note: actual product)
|
