mobile phone monitor
intelligent wireless monitor ip camera
temperature humidity Detection
two-way voice intercom
|
|
Model
|
SY-PT1C
|
|
Image Sensor
|
Image Sensor
|
720P 8135+1045
|
|
Display Resolution
|
1MP, 1280 x 720(720P), 640 x 480(VGA), 320 x 240(QVGA)
|
|
Min. Illumination
|
0.5Lux(0LUX on)
|
|
Audio
|
Input/Output
|
Built in Microphone, 3.5mm audio Jack output
|
|
Audio Compression
|
G.711, ADPCM/32kbps
|
|
Video
|
Image Compression
|
H.264
|
|
Light Frequency
|
50Hz, 60Hz
|
|
Image Resolution
|
1MP, 1280 x 720(720P)
|
|
Image frame rate
|
1~25fps
|
|
View
|
H.264 dual streaming
|
|
Image adjust
|
The brightness, contrast, saturation, chromaticity, is adjustable
|
|
White balance
|
Automatic, Indoor, outdoor , is adjustable
|
|
Infrared mode
|
Automatic , manual (on/off)
|
|
Network
|
Ethernet
|
One 10/100Mbps RJ-45
|
|
Supported Protocol
|
TCP/IP,UDP/IP,HTTP,SMTP,FTP,DHCP,DDNS,UPNP
|
|
Wireless Standard
|
WIFI(IEEE802.11b/g/n)
|
|
Data Rate
|
802.11b: 11Mbps(Max.) 802.11g: 54Mbps(Max.)
|
|
802.11n:150Mbps(Max.)
|
|
Support IP address
|
static IP address, dynamic IP address
|
|
Hardware Interface
|
POWER Interface
|
DC 5V/2.0A (EU,US,UK adapter or other types optional)
|
|
Power Consumption ,8 Watts
|
|
Audio Input/Output
|
Built in audio input, One audio output jack.
|
|
Reset Buttons
|
One Reset
|
|
Wireless Interface
|
WIFI antenna
|
|
Other
|
Pan/Tilt Angle
|
Horizontal:350° & Vertical: 90°
|
|
Environment
|
Operate Temp
|
-20° ~ 55°C (32°F ~ 131°F)
|
|
Operate Humidity
|
10% ~ 80% non-condensing
|
|
Storage Temp
|
-20°C ~ 60°C(14°F ~ 140°F)
|
|
Storage Humidity
|
0% ~ 90% non-condensing
|
|
Certification
|
CE FCC
|
|
|
|
